CV Axle Set for Can-Am Maverick Sport 1000 & Commander 1000

SKU Z.20485 705402030, 705402031 Category Tags ,

CV Axle Set for Can-Am Maverick Sport 1000 & Commander 1000

This is a full set of CV axles for a Can-Am UTV/SXS.

They fit the following 4×4 models:

2021-2023 Commander 1000 STD/DPS (excluding XT, XTP, XMR)

2021-2023 Commander MAX 1000 STD/DPS (excluding XT, XTP, XMR)

2019-2023 Maverick Sport 1000 STD/DPS (excluding XMR, XXC, XRC)

2019-2023 Maverick Sport MAX 1000 STD/DPS (excluding XMR, XXC, XRC)

*Made as an OEM replacement, and not intended for lifted/ modified vehicles

*These are the axles for Base & DPS models

Product features:

Stronger than OEM, 4340 chromoly steel axle bars

Greased with a moly based grease to provide superior joint lubrication

Fitted with neoprene CV boots for added wear & puncture resistance

Inboard spline count: Fronts – 21, Rears – 24

Outboard spline count: Fronts – 29, Rears – 29

Compressed axle length (mm): FL – 703, FR – 662, RL – 680, RR – 680

Replaces OEM # (fronts) 705402031, 705402030, (rears) 705502552
