Front Axles & Wheel Bearing Kits for Arctic Cat 300 98-01 & 500 01 4×4

SKU Z.20596 0402-249, 1502-441, 0402-179 Category Tags ,

Front Axles & Wheel Bearing Kits for Arctic Cat 300 98-01 & 500 01 4×4

This is a set of new Front CV axles & wheel bearing/seal kits for a Arctic Cat ATV.They fit the following 4×4 models:1998-2001 … 3002001 … 500Front, Left & Right*Not intended for use in lifted vehiclesProduct features:
Stronger than OEM, chromoly forged steel axle bar
Greased with a moly based grease to provide superior joint lubrication
Fitted with neoprene CV boots for added wear & puncture resistance
High speed bearings manufactured for long life
Double lip seals made to keep grease in and dirt out
Inboard CV joint spline count: 20 (both)
Outboard CV joint spline count: 21 (both)
Compressed overall axle length: Left- 417 mm, Right- 456 mm
Replaces OE # (axles) 0402-249 1502-441, 0402-179 1502-440, (bearings & seals) 0402-275, 0402-089, 0402-069
