Front Axles & Wheel Bearings for Can-Am Outlander XMR 650, 800, 850 & 1000
Front Axles & Wheel Bearings for Can-Am Outlander XMR 650, 800, 850 & 1000 - Image 2

Front Axles & Wheel Bearings for Can-Am Outlander XMR 650, 800, 850 & 1000

SKU Z.20393 705401384, 705400757, 705400088 Category Tags ,

Front Axles & Wheel Bearings for Can-Am Outlander XMR 650, 800, 850 & 1000

This is a pair of new Front CV axles & wheel bearings for a Can-Am ATV.They fit the following 4×4 applications:2016 … Outlander XMR 5702013-2018 … Outlander XMR 6502015 … Outlander XMR 800R2016-2018 … Outlander XMR 8502013-2015 … Outlander XMR 1000Front, Left & Right*Not intended for use in lifted vehiclesProduct features:
Stronger than OEM chromoly forged steel axle bar
Greased with a moly based grease to provide superior joint lubrication
Fitted with neoprene CV boots for added wear & puncture resistance
High speed bearing manufactured for long life
Double lip seal made to keep grease in and dirt out
Inboard CV joint spline count: 21 (both)
Outboard CV joint spline count: 26 (both)
Compressed overall axle length: Left 515.5 mm, Right 558 mm
