Pair of Front Axles for Suzuki King Quad 500 & 750 EPS 2009-2021
Pair of Front Axles for Suzuki King Quad 500 & 750 EPS 2009-2021 - Image 2
Pair of Front Axles for Suzuki King Quad 500 & 750 EPS 2009-2021 - Image 3

Pair of Front Axles for Suzuki King Quad 500 & 750 EPS 2009-2021

SKU Z.20576 54901-31G30, 54901-31G31 Category Tags ,

Pair of Front Axles for Suzuki King Quad 500 & 750 EPS 2009-2021

This is a pair of new Front CV axles for a Suzuki ATV.They fit the following 4×4 models:2009-2018 … King Quad 500 EPS (EPS models only)2019-2021 … King Quad 500 & 500 EPS2009-2018 … King Quad 750 EPS (EPS models only)2019-2021 … King Quad 750 & 750 EPSFront, Left & Right side*Not intended for use in lifted vehiclesProduct features:
Stronger than OEM chromoly forged steel axle bar
Greased with a moly based grease to provide superior joint lubrication
Fitted with neoprene CV boots for added wear & puncture resistance
Inboard CV joint spline count: 20 (both)
Outboard CV joint spline count: 20 (both)
Compressed overall axle length: 517 mm (both)
Replaces Suzuki OEM # 54901-31G30, 54901-31G31
