Rear CV Axle & Wheel Bearing for Arctic Cat Wildcat 1000 2012-2015
Rear CV Axle & Wheel Bearing for Arctic Cat Wildcat 1000 2012-2015 - Image 2
Rear CV Axle & Wheel Bearing for Arctic Cat Wildcat 1000 2012-2015 - Image 3

Rear CV Axle & Wheel Bearing for Arctic Cat Wildcat 1000 2012-2015

SKU Z.20552 1502-914, 1402-027, 1402-809 Category Tags ,

Rear CV Axle & Wheel Bearing for Arctic Cat Wildcat 1000 2012-2015

This is a new rear CV axle and wheel bearing for an Arctic Cat UTV.They fit the following 4×4 models:2012-2015 ….. Wildcat 1000(fits: GT, Standard, Limited, 4, X and 4X models)Rear, Left or Right*Not intended for use in lifted vehiclesProduct features:
Stronger than OEM chromoly forged steel axle bar
Greased with a moly based grease to provide superior joint lubrication
Fitted with neoprene CV boots for added wear and puncture resistance
High speed bearing manufactured for long life
Double lip seal made to keep grease in and dirt & water out
Inboard CV joint spline count: 27
Outboard CV joint spline count: 27
Compressed overall axle length: 710.5 mm
Replaces Arctic Cat OEM # 1502-914, 1402-027, 1402-809
