Rear CV Axles for Can-Am Outlander & Renegade 650 850 & 1000 4x4

Rear CV Axles for Can-Am Outlander & Renegade 650 850 & 1000 4×4

SKU Z.20658 705502710, 705502711 Category Tags ,

Rear CV Axles for Can-Am Outlander & Renegade 650 850 & 1000 4×4

This is a pair of new, fully assembled, CV axles for a Can-Am ATV.

They fit REAR, LEFT & RIGHT on the following (excluding XMR models):

2019-2023 Outlander 650/MAX 4×4

2019-2023 Outlander 850/MAX

2019-2023 Outlander 1000/MAX 4×4

2019-2022 Renegade 570

2019-2022 Renegade 850

2019-2023 Renegade 1000

(please note these will not fit XMR models)

*Made as an OE replacement, and is not intended for lifted/ modified vehicles

Product features:

Stronger than OEM chromoly forged steel axle bars

Greased with a moly based grease to provide superior joint lubrication

Fitted with neoprene CV boots for added wear and puncture resistance

Inboard CV joint spline count: 24 (both)

Outboard CV joint spline count: 26 (both)

Compressed overall axle length: Left – 575mm, Right – 535mm
