Rear Left Axle & Bearing for Can-Am XMR Outlander & Renegade, 705503025
Rear Left Axle & Bearing for Can-Am XMR Outlander & Renegade, 705503025 - Image 2
Rear Left Axle & Bearing for Can-Am XMR Outlander & Renegade, 705503025 - Image 3

Rear Left Axle & Bearing for Can-Am XMR Outlander & Renegade, 705503025

SKU Z.20350 705503025, 705502712, 293350040 Category Tags ,

Rear Left Axle & Bearing for Can-Am XMR Outlander & Renegade, 705503025

This is a new CV axle and wheel bearing for a Can-Am XMR ATV.

They fit REAR, LEFT (driver side) on the following models

2019-2023 … Outlander XMR 650

2019-2023 … Outlander XMR 850

2019-2023 … Outlander XMR 1000

2020-2021 … Renegade XMR 570

2020-2023 … Renegade XMR 1000

*Made as OE an replacement, and is not intended for lifted/ modified vehicles

Product features:

Stronger than OEM chromoly forged steel axle bar

Greased with a moly based grease to provide superior joint lubrication

Fitted with neoprene CV boots for added wear and puncture resistance

High speed bearing manufactured for long life

Double lip seal made to keep grease in and dirt out

Inboard CV joint spline count: 24

Outboard CV joint spline count: 26

Compressed overall axle length: 574 mm

Replaces OEM # (axle) 705503025, 70550271, (bearing) 293350040, 705400088, 293350118
