Rear Right Axle & Bearing for Can-Am XMR Outlander & Renegade, 705503024
Rear Right Axle & Bearing for Can-Am XMR Outlander & Renegade, 705503024 - Image 2
Rear Right Axle & Bearing for Can-Am XMR Outlander & Renegade, 705503024 - Image 3

Rear Right Axle & Bearing for Can-Am XMR Outlander & Renegade, 705503024

SKU Z.20390 705503024, 705502713, 293350040 Category Tags ,

Rear Right Axle & Bearing for Can-Am XMR Outlander & Renegade, 705503024

This is a new CV axle & wheel bearing for a Can-Am XMR ATV.

They fit REAR, RIGHT (passenger side) on the following models

2019-2023 … Outlander XMR 650

2019-2023 … Outlander XMR 850

2019-2023 … Outlander XMR 1000

2020-2021 … Renegade XMR 570

2020-2023 … Renegade XMR 1000

*Made as OE an replacement, and is not intended for lifted/ modified vehicles

Product features:

Stronger than OEM chromoly forged steel axle bar

Greased with a moly based grease to provide superior joint lubrication

Fitted with neoprene CV boots for added wear and puncture resistance

High speed bearing manufactured for long life

Double lip seal made to keep grease in and dirt out

Inboard CV joint spline count: 24

Outboard CV joint spline count: 26

Compressed overall axle length: 535 mm

Replaces OEM # (axle) 705503024, 705502713, (bearing) 293350040, 705400088, 293350118
