Set of Axles for Polaris Ranger 500 & 700 4×4 2009 / 800 6×6 2010-2017

SKU Z.20473 2204857, 1332502, 1332575 1332647 Category Tags ,

Set of Axles for Polaris Ranger 500 & 700 4×4 2009 / 800 6×6 2010-2017

This is a set of 4 new CV axles for a Polaris UTV

They will fit the following models:

2009 4×4 Ranger 500

2009 Ranger 4×4 XP 700 (excluding Crew)

2010-2017 6×6 Ranger 800

*Axles made as an OE replacement, and not intended for lifted/ modified vehicles

Product features:

Stronger than OEM, 4340 chromoly steel axle bars

Greased with a moly based grease to provide superior joint lubrication

Fitted with neoprene CV boots for added wear & puncture resistance

Inboard CV joint spline count: FL – 22, FR – 22, RL – 29/27, RR – 27

Outboard CV joint spline count: Fronts – 26, Rears – 26

Compressed overall axle length: FL – 664 mm, FR – 664 mm, RL – 705 mm, RR – 660 mm
